Fully Automatic Wire Cutting, Stripping, Twisting & Tinning Machine

6.10 Lac / Piece

1 Piece (MOQ)

Business Type Manufacturer, Exporter, Supplier
Finishing Polished
Color White
Condition New
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Automatic Grade
Fully Automatic
Power Source
Electric
Power Consumption
220V/110V/50/60HZ
Usage
Industrial
Voltage
220V
Packaging Type
Wooden Box
Machine Weight
480KG
Rated Current
220V/110V/50/60HZ
Phase
Single Phase
Warranty
1 Year
Air Consumption
220V/110V/50/60HZ
Motor Speed
1200pcs/hour
Technology Used
Wire Crimping Machine
Cutting Frequency
220V/110V/50/60HZ
Working Space For Machine
1210*770*1370mm
Cutting Accuracy
220V/110V/50/60HZ
Machine Dimensions(L*W*H)
1210 x 770 x 1370 mm
Air Supply
0.5~0.7 Mpa
Twisting Length
3~9 mm
Tinning Length
0.5~9 mm
Stripping Length
0-9 mm
Cutting Length
30~550 mm(Longer Can Be Customised)
Cutting Tolerance
0.2+0.02*Lmm
Port
transport , courier
Delivery Time
15 To 20 Day
Packaging Details
Single package size: 121X77X137 cm
Single gross weight: 480.000 kg
  • Display Touch panel, Function Cut, single/double stripping, twisting and tinning
  • Production rate less than 100mm, 6000~8000pcs



Available cable

  • 20-32AWG, 8-wires once , 6400-10000pcs/H
  • 16-20AWG, 3-wires once, 2700-4000pcs/H
  • Applicable wire range
    AWG34-AWG18
    Stripping
    0.1-6mm (7-20mm can be customized)
    Cut precision
    ±(0.5+0.002*L) mm, L=cut length
    Cutting length
    50-400mm
    Capacity
    1200pcs/hour
    Crimping force
    2.0T
    Tinning length
    2-7mm (7-20mm can be customized)
    Air pressure
    0.5-0.7Mpa
    Detection
    Wire run out, low air pressure, terminate error(Crimping force monitor is optional)
    Power
    220V/110V/50/60HZ
    Weight
    480Kg
    Dimension
    1210*770*1370mm
