Sleeve Cutting Machine

80,500.00 / piece

1 Piece (MOQ)

Business Type Manufacturer, Exporter, Supplier
Automation Grade Automatic
Usage/Application Industrial
Country of Origin India
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Condition
New
Speciality
Less Power Consumption, Robust Design
Packaging Type
Wooden Packaging
Port
transport , courier
Delivery Time
1 To 7 Day
Packaging Details
cartoon box
Weight - 32kg
Size
430*300*350mm
Power
750W
Power supply
AC220V 50/60HZ
Speed
1~99 optional
Efficiency
120-150/min,50mm
System
Chinese/English system
Blade
Import speed steel
Cutting length
1-999mm
Cutting width
1-100mm(160,200,400 optional,support customize)
Accuracy
0.1mm
Weight
32kg
Size
430*300*350mm

Feature


(1)High-speed feeding, computer pipe cutting machine is controlled by microcomputer program with precision of 0.1mm.
(2) Adjustable cutter speed.
(3)Length and speed are continuously adjustable.
(4)Automatic group accumulation and total accumulation count.
(5)Batch pause and delay time can be set.
(6) Automatically shuts down when no feeding.
(7) Automatically cut all kinds of tubular and ribbon materials.
(8) High-speed stepping motor accurately controls the length of the tube cutting; the length and speed of the tape are adjustable.
(9) Cutter time protection; total number setting; split setting; split suspension time adjustable.
(10)A variety of manual operations are available to facilitate debugging.
(11) Simple and convenient operation; also can display English version.
(12)Using a special mechanical structure and special cutters, with special software control, to solve the problem of uneven incisions of silicone tubes of other manufacturers. Achieve a flat incision and accurate length.

Application
This machine is suitable for heat shrinkable tube, silicone tube, Teflon tube, fiberglass tube, PVC tube, PE tube, silicone tube,oil resistant tube, railway tube, braided network tube, fluoroplastic tube, anticorrosion tube, yellow-green tube, Patterned tube,medium and thick-walled sheath, double-walled tube, marking tube, electrolytic capacitor PVC sleeve, PVC plastic tape,cable,cable tie line, plastic hose, insulating paper, copper foil, copper sheet, double-sided tape, PE film bag, leather,non-woven fabric, acetate cloth, rubber pad, cotton yarn belt, safety belt, elastic belt, color belt, bag track, plastic belt,hook and loop belt, battery separator, nickel sheet, diffusion sheet, reflective film, conductive cloth, foam, PET, Velcro, zipper and other belt-shaped or tube-shaped fixed-length cutting.
