Twitter| Business Type | Manufacturer, Exporter, Supplier |
| Color | White |
| Condition | New |
| Automatic Grade | Automatic |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Power Source
Electric
Power Consumption
AC110V-220V, 50/60HZ
Usage
Industrial,Diameter of Wire 0.1-4.5 Sqmm
Voltage
220V
Packaging Type
Carton Box, Wooden Box
Phase
Single Phase
Warranty
1 Year
Air Consumption
no
Model No.
IE-220
Output
10000- 12000 Pcs/Hour
Intelligent Control
Keypad Type
Cutting Length
40-99999 mm
Stripping Length
5-30 mm
Middle Stripping
Yes At 10 Places
Save Program
100 Program
Type of Wire Cutting
Electronic Cable, Teflon Cable, Silicone Cable,Fiberglass Cable, Isolation Cable Sheathed Cable
Wire Running At a Time
2 Wire Up to 4.5 Sqmm
Watt
180 Watt
Motor Type
Stepper Motor
Drive
3
Port
transport , courier
Delivery Time
1 To 7 Day
Packaging Details
Carton Box
●Cutting and Stripping Machine Detail
1.It support the computer control and keystrokes operation.
2.The high speed wire peeling can freely set the wire length, cord top, wire tail, peeling length within the peeling range.
3.It has the measuring and with the stable performance and the convenient operation
2.The high speed wire peeling can freely set the wire length, cord top, wire tail, peeling length within the peeling range.
3.It has the measuring and with the stable performance and the convenient operation
●Cutting and Stripping Machine Product
Full automatic cutting and stripping machine, easy to setting cutting and stripping length in machine. Digital setting option,full automatic mode.
|
SPECIFICATIONS FOR Automatic cutting Machine
|
|
|
Technical Index
|
Tech-Parameters
|
|
SIZE
|
450*450*360mm
|
|
WEIGHT
|
36KG
|
|
POWER
|
AC110V-220V, 50/60HZ
|
|
CUTTING LENGTH
|
0.1MM~99999MM
|
|
STRIPPING LENGTH
|
0.1MM~99MM
|
|
TWISTING LENGTH
|
OPTIONAL
|
|
APPLICABLE CABLE OD
|
AWG14~AWG32
|
|
Other
|
different kinds of model for different OD cable
|
Looking for "IE-220 High Speed Wire Cutting & Stripping Machine" ?
